Electrical Requirements
Wolf downdraft ventilation systems
require a separate, grounded 120V,
60 Hz power supply. The service
should have its own 15 amp circuit
breaker and a grounded 3-prong
receptacle should be located within
the reach of the 2' (.6 m) power
cord. The specific location of the
outlet is not critical, as long as it is
within reach of the power cord that is
located mid-way, top and bottom on
the right side of the downdraft.
IMPORTANT NOTE: If the 30" (762)
downdraft is being installed in a 30"
(762) wide cabinet, or the 36" (914)
downdraft in a 36" (914) wide
cabinet, the outlet cannot be located
on the back wall of the cabinet. The
outlet may be placed in adjacent
cabinetry. Locate electrical within the
shaded area shown in the illustration.
IMPORTANT NOTE: A ground fault
circuit interrupter (GFCI) is not
recommended and may cause inter-
ruption of operation.
You must follow all National Electrical
Code regulations. In addition, be
aware of local codes and ordinances
when installing your service.
Discharge Location
Wolf downdraft systems have an
adjustable discharge that will allow
you to negotiate ducting around floor
joists and other obstacles. Three
different discharge locations are avail-
able with side to side adjustment for
accurate alignment of ductwork.
Refer to the illustration for discharge
location and adjustment.
24"min
(610)
36"min (914)
FOR MODEL DD36
30"min (762)
FOR MODEL DD30
E
3
1
/2" (89)
ELECTRICAL
LOCATION IN
ADJACENT RIGHT
SIDE CABINET
4"min (102)
10" (254)
E
3
1
/2" (89)
4"min (102)
10" (254)
Electrical placement for 30" (762) and 36" (914) downdrafts.
DISCHARGE CUTOUT
DIMENSIONS:
10
1
/4
" (260) x 3
1
/2
" (89)
INTERNAL BLOWER
14
1
/4
" (362) x 3
1
/2
" (89)
REMOTE BLOWER
CENTERLINE OF COUNTERTOP CUTOUT
16
3
/8
" (416)
INTERNAL BLOWER
21
1
/2
" (546)
REMOTE BLOWER
5
1
/2
" (140)
INTERNAL BLOWER
4
1
/4
" (108)
REMOTE BLOWER
C
L
22
1
/8
" (562)
INTERNAL BLOWER
19" (483)
REMOTE BLOWER
RIGHT
DISCHARGE
LOCATION
LEFT
DISCHARGE
LOCATION
CENTERLINE OF COUNTERTOP CUTOUT
5
1
/2
" (140)
INTERNAL BLOWER
4
1
/4
" (108)
REMOTE BLOWER
C
L
NOTE: Measurements are to centerline of duct cutouts
ADJUSTMENT:
5" MAX (127)
REMOTE BLOWER
ADJUSTMENT:
1" (25) - 7" (178)
INTERNAL BLOWER
2
1
/2
" MAX (165)
REMOTE BLOWER
BOTTOM
DISCHARGE
LOCATION
Discharge location and adjustment for downdraft ventilation system.
W OLF C OOKTOP V ENTILATION
Dimensions in parentheses are in millimeters unless otherwise specified.
