W OLF P RO S ERIES V ENTILATION
PLANNING
INFORMATION
22" (559) Deep Low Profile
Wall Hoods –
Available in 30" (762), 36" (914),
42" (1067) and 48" (1219) widths.
(I) models include a 600 cfm internal
blower. These hoods are not recom-
mended for use with Wolf dual fuel
range, gas range and rangetop
models with a charbroiler or griddle.
24" (610) Deep Wall Hoods –
Available in 30" (762), 36" (914),
42" (1067), 48" (1219), 54" (1372),
60" (1524) and 66" (1676) widths.
27" (686) Deep Wall Hoods –
Available in 30" (762), 36" (914),
42" (1067), 48" (1219), 54" (1372),
60" (1524) and 66" (1676) widths.
Pro Series Island Hoods –
Available in 36" (914), 42" (1067),
54" (1372), and 66" (1676) widths.
The overall dimensions illustrations of
the Pro Series wall and island hoods
include the optional rail dimensions.
Overall width, height and depth
dimensions will remain the same if a
decorative rail is not to be used.
Optional classic stainless steel duct
covers are available in heights of 6"
(152) and 12" (305) for all Pro Series
wall and island hoods. Contact your
Wolf dealer for information on
optional accessories.
OVERALL WIDTH
27" (686)
OVERALL DEPTH
12"
(305)
18"(457)
OVERALL
HEIGHT
2"
(51)
4"(102)
3
/4" (19)
DIAMETER
OF RAIL
10"(254)
OVERALL
HEIGHT
OVERALL WIDTH
4"(102)
22" (559)
OVERALL DEPTH
12"
(305)
2"
(51)
3
/4" (19)
DIAMETER
OF RAIL
OVERALL WIDTH
4"(102)
24" (610)
OVERALL DEPTH
12"
(305)
18"(457)
OVERALL
HEIGHT
2"
(51)
3
/4" (19)
DIAMETER
OF RAIL
TOP WIDTH
(SUBTRACT 18" FROM OVERALL WIDTH)
18" (457)
OVERALL
HEIGHT
OVERALL WIDTH
34" (864)
OVERALL DEPTH
13"
(330)
4"(102)
2"
(51)
3
/4" (19)
DIAMETER
OF RAIL
2"
(51)
Pro Series 22" (559) Deep Low Profile Wall Hood – Overall Dimensions
Pro Series 24" (610) Deep Wall Hood – Overall Dimensions
Pro Series 27" (686) Deep Wall Hood – Overall Dimensions
Pro Series Island Hoods – Overall Dimensions
Dimensions in parentheses are in millimeters unless otherwise specified.
