30" TO 36"
(762 - 914)
COOKING SURFACE
TO BOTTOM OF
VENTILATION HOOD
10" (254) – 22"D HOOD
18" (457) – 24"D HOOD
HEIGHT OF HOOD
WALL HOOD
DUCTWORK INSTALLATION
THROUGH ROOF
37" (940)
TO COOKING
SURFACE
22" (559)
24" (610)
DEPTH OF HOOD
ROOF CAP OR REMOTE BLOWER
8" ROUND DUCT (22"D HOOD)
10" ROUND DUCT (24"D HOOD)
SOFIT OR CABINET
OR DUCT COVER
WALL CAP
OR REMOTE BLOWER
*HORIZONTAL DISCHARGE IS ONLY APPLICABLE ON 22" WALL HOODS (excluding W302210I and W362210I)
AND 24" WALL HOODS USED WITH A WBLOWER-120INT (804702) OR ANY WOLF REMOTE BLOWER.
WBLOWER-90INT (805086) IS NOT FOR USE IN HORIZONTAL DISCHARGE APPLICATIONS.
DUCTWORK INSTALLATION
THROUGH WALL
DISCHARGE COLLAR
HORIZONTAL
DISCHARGE*
VERTICAL DISCHARGE
TRANSITION**
17-3/4"W x 4-1/4"D TO 8" ROUND
9-3/8"H (22"D HOOD)
22-1/4"W x 9"D TO 10" ROUND
10"H (24"D HOOD)
**DIMENSIONS FOR TRANSITION
INCLUDES FLANGES
PLANNING
INFORMATION
Blower Considerations
Models W302210I and W362210I
come with internal blowers, all other
Pro Series wall and island hoods are
shipped without the blower assembly.
Internal or remote blower assemblies
are available. For Pro Series wall
hoods, the remote blower can be
mounted on the roof or an exterior
wall. For island hoods, the remote
blower will be mounted on the roof.
The blower assemblies are quite
varied, and depending on the
amount of air you want to move and
the length of the duct run, you have
many options. A straight, short duct
run with a limited number of elbows
and transitions will allow the ventila-
tion hood to perform most efficiently.
A remote mounted blower will
minimize the amount of blower
noise, but will not eliminate the noise
completely.
IMPORTANT NOTE: Install this venti-
lation hood only with a Wolf blower.
Refer to the Pro Series ventilation
charts on pages 81-82 for recommen-
dations and blower options.
Ducting Considerations
Wolf Pro Series 22" (559) and 24"
(610) deep wall hoods have an
adjustable discharge location which
can run vertically or horizontally.
Horizontal discharge is only applica-
ble on 22" (559) wall hoods (exclud-
ing W302210I and W362210I) and
24" (610) wall hoods used with a
WBLOWER-120INT or any Wolf
remote blower. WBLOWER-90INT is
not for use in horizontal discharge
applications. Refer to the illustration
for ducting options.
Ducting considerations for 22" (559) and 24" (610) deep Pro Series wall hoods.
