13
Setting Up the Wood Chipper
Step 22: Attach the discharge chute. Step 23: Attach the battery cables.
(red is positive, green is negative)
Setting Up the Wood Chipper (continued)
Step 24: (Left) Attach the infeed bin
by connecting the hinged side first,
then bolting the other side as shown.
Step 26: Attach the exhaust diverter
as shown (7mm)
Step 25: Connect the safety bar wire
to the wiring harness.
