Your WoodMaxx backhoe is one of kind in the industry. It is the
only backhoe in its class that allows the user to switch between
ISO and SAE control positions.
The lever is located near the
left foot of the operator.
GENERAL OPERATIONGENERAL OPERATION
If you purchased the hydraulic thumb option with your back-
hoe, you will need to change hydraulic ow from the right
leg over to the hydraulic thumb in order to use it.
The lever is located near the operator’s right leg (if sitting in
the backhoe seat).
You will nd this label located
near this handle. It indicates
which way to push the lever to
activate hydraulics to the thumb
or the stabilizer leg, respectively.
