WM-6600 BACKHOE CYLINDER SPECS
WM-7600
7’ BACKHOE
CYLINDER
DIAMETER
ROD
DIAMETER
STROKE
WORK
PRESSURE
BOOM
CYLINDER
3-1/8” 1-3/8” 18-1/2” 2320psi
DIPPER
CYLINDER
2-7/8” 1-3/8” 18-1/8” 2320psi
BUCKET
CYLINDER
2-3/8” 1-3/8” 15-3/8” 2320psi
SWING
CYLINDER
2-3/8” 1” 9” 2320psi
STABILIZER
CYLINDER
2-2/8” 1-1/8” 11-1/4” 2320psi
WM-7600 BACKHOE CYLINDER SPECS
WM-8600
8’ BACKHOE
CYLINDER
DIAMETER
ROD
DIAMETER
STROKE
WORK
PRESSURE
BOOM
CYLINDER
3-1/2” 1-3/4” 17-3/4” 2320psi
DIPPER
CYLINDER
3-1/4” 1-3/4” 22-3/4” 2320psi
BUCKET
CYLINDER
2-3/4” 1-1/2” 15” 2320psi
SWING
CYLINDER
2-3/8” 1” 9” 2320psi
STABILIZER
CYLINDER
2-2/8” 1-3/8” 11-1/4” 2320psi
WM-8600 BACKHOE CYLINDER SPECS
BACKHOE CYLINDER SPECS
TECHNICAL SPECIFICATIONSTECHNICAL SPECIFICATIONS
