4 Introduction
MAN1177
(
07/28/2023
)
SPECIFICATIONS
RT42.30/RTR42.30 RT48.30/RTR48.30 RT60.40/RTR60.40 RT72.40/RTR72.40
Tilling Width 41" 47" 59" 71"
Maximum Tilling Depth 7" 7" 7" 7"
Operating Weight 478 lbs / 483 lbs 502 lbs / 507 lbs 570 lbs / 578 lbs 628 lbs / 636 lbs
Rotor Swing Diameter 15" 15" 15" 15"
Number of Blade Flanges 5 6 7 9
Number of Blades 20 24 28 36
Drive Type Gear Gear Gear Gear
Tractor PTO Speed 540 RPM
Rotor Speed 210 RPM
Tractor Hitch Limited Category 1 & Category 1 Category 1
Tractor Horsepower 12 - 30 HP 15 - 35 HP 18 - 40 HP 20 - 50 HP
Skid Shoe Adjustments 5 x 1" 5 x 1" 5 x 1" 5 x 1"
Offset 3" 3" 2.3" 2.3"
Gearbox Oil Capacity 1.2 Qt SAE 80W-90
Side Drive Oil Capacity 3 QT SAE 80W-90
GENERAL INFORMATION
■ Some illustrations in this manual show the
mower with safety shields removed to provide a
better view. The mower should never be operat-
ed with any safety shielding removed.
The purpose of this manual is to assist you in oper-
ating and maintaining your cutter. Read it carefully.
It furnishes information and instructions that will help
you achieve years of dependable performance. These
instructions have been compiled from extensive eld
experience and engineering data. Some information
may be general in nature due to unknown and vary-
ing operating conditions. However, through experience
and these instructions, you should be able to develop
procedures suitable to your particular situation.
The illustrations and data used in this manual were cur-
rent at the time of printing but, due to possible inline
production changes, your machine may vary slightly in
detail. We reserve the right to redesign and change the
machines as may be necessary without notication.
Throughout this manual, references are made to right
and left directions. These are determined by standing
behind the equipment facing the direction of forward
travel. Blade rotation is clockwise (left wing) and coun-
terclockwise (right wing and center section) as viewed
from the top of the cutter.
WARNING
¡LEA EL INSTRUCTIVO!
Si no lee Ingles, pida ayuda a
alguien que si lo lee para que le
traduzca las medidas de seguridad.
