Woods RT72.40E User Manual

4 Introduction
MAN1249 (2/28/2018)
SPECIFICATIONS
GENERAL INFORMATION
 Some illustrations in this manual show the
equipment with safety shields removed to provide
a better view. This equipment should never be
operated with any necessary safety shielding
removed.
The purpose of this manual is to assist you in operating
and maintaining your rotary tiller. Read it carefully. It
furnishes information and instructions that will help you
achieve years of dependable performance. These
instructions have been compiled from extensive field
experience and engineering data. Some information
may be general in nature due to unknown and varying
operating conditions. However, through experience
and these instructions, you should be able to develop
procedures suitable to your particular situation.
The illustrations and data used in this manual were cur-
rent at the time of printing but, due to possible inline
production changes, your machine may vary slightly in
detail. We reserve the right to redesign and change the
machines as may be necessary without notification.
Throughout this manual, references are made to right
and left directions. These are determined by standing
behind the equipment, facing the direction of the for-
ward travel.
RT42.30E/RTR42.30E RT48.30E/RTR48.30E RT60.40E/RTR60.40E RT72.40E/RTR72.40E
Tilling Width
1.07m (42") 1.22m (48") 1.52m (60") 1.83m (72")
Maximum Tilling Depth
177.8mm (7") 177.8mm (7") 177.8mm (7") 177.8mm (7")
Operating Weight
216.8kg / 219.1kg
(478 lbs / 483 lbs)
227.7kg / 230.0kg
(502 lbs / 507 lbs)
259.0kg / 262.2kg
(571 lbs / 578 lbs)
284.9kg / 288.5kg
628 lbs / 636 lbs
Rotor Swing Diameter
381mm (15") 381mm (15") 381mm (15") 381mm (15")
Number of Blade Flanges
5679
Number of Blades
20 24 28 36
Drive Type
Gear Gear Gear Gear
Tractor PTO Speed
540 RPM 540 RPM 540 RPM 540 RPM
Rotor Speed
210 RPM 210 RPM 210 RPM 210 RPM
Tractor Hitch
Limited Category 1 & Category 1 Category 1
Tractor Horsepower
22.4 kW (30 HP) 26.1kW (35 HP) 29.8kW (40 HP) 37.3kW (50 HP)
Skid Shoe Adjustments
5 x 25.4mm (1") 5 x 25.4mm (1") 5 x 25.4mm (1") 5 x 25.4mm (1")
Offset
76.2mm (3") 76.2mm (3") 58.4mm (2.3") 58.4mm (2.3")
Gearbox Oil Capacity
1.14 L (1.2 Qt)
SAE 80W-90
1.14 L (1.2 Qt)
SAE 80W-90
1.14 L (1.2 Qt)
SAE 80W-90
1.14 L (1.2 Qt)
SAE 80W-90
Side Drive Oil Capacity
2.84 L (3 Qt)
SAE 80W-90
2.84 L (3 Qt)
SAE 80W-90
2.84 L (3 Qt)
SAE 80W-90
2,84 L (3 Qt)
SAE 80W-90
WARNING
