723PLUS Control Specifications
Input Power
Low Voltage Model 18–40 Vdc (24 or 32 Vdc nominal)
High Voltage Model 90–150 Vdc (125 Vdc nominal)
Power Consumption 40 W nominal
Inrush Current (Low Voltage Model) 7 A for 0.1 ms
Inrush Current (High Voltage Model) 22 A for 15 ms
Inputs
Speed Signal Inputs (2)
Speed Input Voltage 1.0–50.0 Vrms
Speed Input Frequency Magnetic Pickup: 400 Hz to 15 kHz
Proximity Switch: 30 Hz to 15 kHz
Speed Input Impedance 10 kΩ ± 15%
Note: EU Directive compliant applications are not currently able to use proximity switches due to the sensitivity of the
switches.
Discrete Inputs (8)
Discrete Input 24 Vdc, 10 mA nominal,18–40 Vdc range
Response Time 10 ms ±15%
Impedance 2.3 kΩ
Note: For Lloyd’s Register applications, use only control-supplied power.
Analog Inputs (4)
Analog Input ±5 Vdc or 0–20 mA, transducers externally powered
Common Mode Voltage ±40 Vdc
Common Mode Rejection 0.5% of full scale
Accuracy 0.5% of full scale
Load Sharing Input
Analog Input 0–4.5 Vdc
Common Mode Voltage ±40 Vdc
Common Mode Rejection 1.0% of full scale
Accuracy 1.0% of full scale
Outputs
Analog Outputs 0–1 or 4–20 mA (2)
Analog Output 0–1 mA or 4–20 mA (max. 600 Ω load)
Accuracy 0.5% of full scale
Analog Outputs 0–20 or 0–200 mA (2)
Analog Output 0–20 mA (max. 600 Ω load) or
0–200 mA (max. 70 Ω load)
Accuracy 0.5% of full scale
Relay Contact Outputs (3)
Contact Ratings 2.0 A resistive @ 28 Vdc; 0.5 A resistive @ 125 Vdc
Environment
Operating Temperature –40 to +70 °C (–40 to +158 °F)
Storage Temperature –55 to +105 °C (–67 to +221 °F)
Humidity 95% at +20 to +55 °C (+68 to +131 °F)
Lloyd’s Register of Shipping Spec. Humidity Test 1
Mechanical Vibration Lloyd’s Register of Shipping Spec. Vibration Test 1
Mechanical Shock US MIL-STD 801C Method 516.2, Proc. I, II, V
EMI/RFI Specification Lloyd’s Register of Shipping Specification
EN 50081–2 and EN 50082–2
Compliance
CSA Certified Class I, Division 2, Groups A, B, C, & D
Marine Listings Lloyd’s Register of Shipping (LR), Germanischer Lloyd (GL), American
Bureau of Shipping (ABS, Low Voltage Models only), Bureau Veritas (BV),
Det Norske Veritas (DNV), Nippon Kaiji Kyokai (NKK), Registro Italiano
Navale (RINA)
European Union (EU) Compliant with EMC Directive 2004/108/EC and Low Voltage Directive
2006/95/EC.
