Page #11 background imageLoading...
Page #11 background image
11
Mains
indicator
On/Off
switch
ST8
(LS)
ST8
(L
R)
ST8
(N
S)
ST15
Pin L
REL 1
Pump
ST12 Pin N
Optional link
Room
thermostat
Transformer
Fuse F2
(1.25A Slow)
Fuse F1
(2A Slow)
N
ST12 Pin L
LIVE
IN
green
Electronics
Electronics
InputsOutputs
Spark Indicators
Settings
Regulator valve
CH
demand
indicator
Red
Spark
electrodes
DHW
demand
indicator
Red
Flame
detect
indicator
Red
Main valve
Main valve
Flow switch
CH sensor
DHW sensor
Flame sense
Overheat cut-off
24V programmer
Reset button
Gas valve mode switch
CH pressure adjust pot
CH Control knob
DHW control knob
Convert AC to low
voltage electronics
Electronics/
microprocessor
(Safety Low Voltage)
Fig. 10. Functional flow diagram.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Worcester 24CDi BF and is the answer not in the manual?

Worcester 24CDi BF Specifications

General IconGeneral
Model24CDi BF
CategoryBoiler
TypeCombi
Fuel TypeGas
Output24 kW
Flue TypeBalanced Flue
MountingWall Mounted
Dimensions760 x 440 x 360 mm
Warranty2 years
Efficiency RatingA
Hot Water Flow Rate9.8 l/min
