10
TO LIGHT THE APPLIANCE
Check that the water valves to the central heating circuit are open.
Check that the grey needle on the pressure gauge is not below
the required pressure.
Switch on the mains electricity. The power on indicator will
light. Set the room thermostat, if fitted, to maximum. Turn the central
heating temperature control knob to ‘MAX’.
The burner will light.
Set the central heating control knob and the room thermostat, if
fitted, to the desired temperature.
Fig. 3. 28i with front panel removed.
Circulating
pump
Front panel
hook
DATA
PLATE
Locating peg
Burner
viewing
window
Gas valve
TO LIGHT AND STOP THE
APPLIANCE
