Worcester 24ijunior - Page 37

37
Re-connect the 3-way
connector and open a
tap to run the turbine.
Is there between 1.5V
and 4.5V across the
green and black
wires/terminals?
Is there continuity in
the main harness?
Disconnect the 3 way
in-line connector to
the turbine.
Is there 5VDC between
the two outer pins
(main harness side)?
Take care not to
damage the pins.
No No
Yes
Yes
Replace control
board.
Replace main
harness.
TEST C
Yes
Replace turbine.
No
