BEND SETS WITH LOW LOSS HEADER
The GB162 cascade system can be installed in various
configurations (Æ fig. 4). By using the bend set the low
loss header can be installed at an angle to the boilers.
The gas pipe is reversible so that the gas connection can
be at the other side of the boilers to the flow and return
connections to the header.
Fig. 4 Cascade system configuration varieties
1 21 2
1 21 2
1 21 2
