Workhorse ATV 1502 - Pump & Valve Assembly; Pump and Valve Assembly Instructions

— Pump & Valve Assembly
PRECISION SPRAY EQUIPMENT
®
, a divison of Green Leaf, Inc. 9490 N BALDWIN ST FONTANET, IN 47851 www.workhorsesprayers.com 888-433-6631
a division of Green Leaf, Inc ®
PRECISION SPRAY EQUIPMENT
PSE
®
PARTS LIST
DESCRIPTIONPART NUMBERQTYITEM
2.2 GPM Pump*640451
11
4.0 GPM Pump*63020111
5.0 GPM Pump*630031
11
Manifold Body
60028912
Elbow (2.2 pumps)
60029113
Elbow (4.0 & 5.0 pumps)600292
1
3
Gauge 0-100 PSI60012914
Inline Valve6002162
5
QD EL 1260028716
5/8" Hose Clamp
60012027
1/2" Hose Clamp600288
1
8
10-24 x 1.25 Screw60013049
Relief Hose Assembly600213
1
10
Suction Hose Assembly
600315311
Cap Assembly (not shown)600298
1
12
Wand Hose Assembly
Relief Hose Assembly
Boom Hose Assembly
if equipped
The Lever adjusts the system pressure by
relieving liquid back to the tank. Adjusting
this lever will increase or decrease pressure
to both the spray wand and the spray boom.
The lever turns the spray
boom on and off
Install Wand Hose Assembly onto
Swivel Barb Assembly, by placing a
Hose Clamp over the open end of the
hose on the Wand Hose Assembly.
Then pressing the open end of the
hose onto the Swivel Barb Assembly
like shown. Secure in place by
tightening the Hose Clamp as shown.
7
Wand Hose Assembly
Boom Hose Assembly
1
1
4
3
2
0
5
6
8
1
9
7
1
*Pump included depends upon model purchased.
