Operation
15
Assembling the hose, extension wands and nozzle
1. Insert the larger end of the hose
9
into the vacuum port
6
until it securely
locks into place (see Fig. C).
2. Connect the smaller end of the hose to an extension wand
8
(see step 1 in Fig. D).
3. Connect the two extension wands together (see step 2 in Fig. D).
4. Connect the end of the extension wand to a desired nozzle
12
,
13
or
14
(see step 3 in Fig. D).
Use the gulper nozzle
12
for tight spaces and picking up larger pieces.
Use the crevice nozzle
13
for hard-to-reach nooks and crannies.
Use the floor nozzle
14
for carpets or hard floors.
Operation
WARNING!
Risk of fire, explosion and health hazard!
If you do not use the vacuum properly, there is an increased risk of
fire, explosion and health hazard.
− Do not operate the vacuum in areas with flammable gases,
vapors or explosive dust in the air.
− Do not vacuum toxic materials.
− Do not use the vacuum as a sprayer of any flammable or
combustible liquid.
− Wear safety eyewear, ear protectors and dust mask for
protection.
Dry vacuuming
− The vacuum is supplied with the reusable cloth filter already fitted
for dry vacuuming.
− If you are using the vacuum to pick up very fine dust, it is
necessary to empty the dust tank and clean or replace the filters
more frequently for best performance.
1. Undo the latches
5
and remove the motor head
4
from the vacuum with the
handle
2
(see Fig. A).
2. Make sure the reusable cloth filter
16
is properly installed.
