Workzone 45151 User Manual

Operation
16
To properly install the reusable cloth filter, fit it onto the filter cage
19
(covered
by the foam filter
18
) and secure it with the clamp ring
17
(see Fig. E).
Make sure there is no gap between the reusable cloth filter and the base of
the filter cage. Any leaks will allow the picked up debris to be blown out of the
blowing port
21
and back into the surroundings.
3. Make sure the disposable filter bag
15
is properly installed.
To properly install the disposable filter bag, fit its opening onto the vacuum port
6
inside the dust tank
7
(see Fig. F).
Position the bag so that it is distributed evenly around the inside of the dust tank.
4. Replace the motor head on the dust tank and engage the latches.
Make sure the latches snap tightly in place and are securely engaged.
5. Assemble the hose
9
, extension wands
8
and a desired nozzle
12
,
13
or
14
(see chapter “Assembling the hose, extension wands and nozzle”).
6. Connect the power cord
3
to a wall outlet.
7. Press the power switch
1
to set it to the “I” position to switch the vacuum on.
8. When done, press the power switch to set it to the “O” position to switch the
vacuum off and unplug the power cord.
Wet vacuuming
The reusable cloth filter, clamp ring and disposable filter bag must be
removed before wet vacuuming.
1. Undo the latches
5
and remove the motor head
4
from the vacuum with the
handle
2
(see Fig. A).
2. Make sure the reusable cloth filter
16
and clamp ring
17
are removed.
To remove them, lift the clamp ring and then the reusable cloth filter off from the
filter cage
19
(see Fig. E).
3. Make sure the foam filter
18
is in place on the filter cage (see Fig. G).
4. Make sure the disposable filter bag
15
is removed.
To remove the filter bag, detach it from the vacuum port
6
.
5. Replace the motor head on the dust tank and engage the latches.
Make sure the latches snap tightly in place and are securely engaged.
6. Assemble the hose
9
, extension wands
8
and a desired nozzle
12
,
13
or
14
(see chapter “Assembling the hose, extension wands and nozzle”).
7. Connect the power cord
3
to a wall outlet.
8. Press the power switch
1
to set it to the “I” position to switch the vacuum on.
