13Amp 7-1/4in. Circular Saw
Operation& Electrical Safety
Always ensure that the saw is switched off and unpluged from
the power supply before making any adjustment.
WARNING
The direction in which the blade rotates has to be the same
as the direction of the arrow marked on the housing. Ensure
that spindle lock button is released.
Before using the saw again, check that the safety devices are in good
working order.
IMPORTANT. After replacing the saw blade, make sure that the saw
blade runs freely by tuming the blade by hand. Plug the machine into a
power socket and run the saw under no load to check that it runs
smoothly before using it to cut any material.
CHANGING THE BLADE CAUTION
• Place saw on its side on a at surface
• Rotate the saw blade by hand whilst depressing spindle lock button until
the blade locks
• Whilst depressing spindle lock button,turn the blade bolt anti-clockwise
using wrench
• Remove the outer blade ange and the blade bolt
• Raise the lower blade guard(3) using lever
• Remove the saw blade from the inner ange and pull out the blade
NOTE
Clean the saw blade ange thoroughly before mounting the new saw
blade. Wipe a drop of oil onto the inner and outer ange where they will
touch the blade.
Mount the new saw blade onto the spindle and against the inner ange
Replace the outer ange and tighten the blade bolt.
Spindle buttonBlade bolt
Flange
