MODEL: HCE2400 PRODUCT CODE: 62005 09/2018
AUS
Assembly/Before operation HCE2400
20
Mounting of extension with variable nozzle (Fig.4)
1 Plug the extension (13) with the variable nozzle (15) into the gun (14) and twist it.
2 Plug in the variable nozzle (15).
3 For removal, press the button (A) and remove the variable nozzle (15).
VIII. Before operation
It is recommend for the power supply to this high pressure washer either to be
connected via a residual current device circuit-breaker, which interrupts the power
ow as soon as the leakage current to earth exceeds 30 mA for 30 ms, or for it to be
equipped with an earth tester.
Before you connect the high pressure washer to the mains supply make sure that
the data on the rating plate are identical to the mains data. Warning! Always pull
the power plug before making adjustments to the high pressure washer
Using the high pressure washer correctly
• The high pressure washer must be stood on a level, stable surface.
• It is recommended that you adopt the correct operating position every time you
use the high pressure washer with one hand on the gun and the other on the
lance.
• Never direct the water jet at electrical lines or the high pressure washer itself.
• Never use the high pressure washer in potentially explosive areas under any
circumstances!
• The operating temperature must be between +5 and + 50 °C.
• Do not cover or modify the lance or the spray nozzles in any way.
• The high pressure washer is designed to be used with cold or lukewarm water
(max. 50 °C); higher temperatures can damage the high pressure washer.
• Do not use water that is dirty, gritty or contains any chemical products, as these
could impair operation and shorten the life of the high pressure washer.
