m Warning! Risk of explosion
Do not spray ammable liquids.
m Warning!
Water that has passed through the non-return valve is not drinkable.
m Warning!
If cleaning agent gets into contact with your skin or into your eye, rinse immediately
with lots of clean water. Then consult a doctor or follow the steps described on the
safety data sheet or provided by the manufacturer of the cleaning agent.
Water inlet connector (Fig. 1/2)
The quick connector (12) has a standard hose coupling system. Plug the hose cou-
pling of the supply hose (min. Ø 1/2“/13 mm) to the quick connector (12).
Always use a reinforced hose with a standard coupling for the water inlet. The hose
should be at least 6 m in length (not supplied).
A backow preventer must be installed between the drinking water and the high
pressure washer! Ask your local plumber about this.
Electrical connections
• Before you connect the high pressure washer to the power supply make sure that
the data on the rating plate are identical to the supply voltage.
• If you use any extension cables, make sure that they are suitable for outdoor use
and have large enough wires:
1 – 10 m: 1.5 mm²
10-30 m: 2.5 mm²
• Insert the power plug on the power cable into the socket outlet.
IX. Operation
m Warning! Be prepared for the recoil force of the emitted water jet! Ensure
that you are standing rmly and that you are holding the gun (14) securely,
otherwise you could injure yourself or other people.
Never operate the high pressure washer with a closed water tap. Dry running
will damage the high pressure washer!
Using the gun (Fig.1/4)
1 Turn on the water tap entirely.
AFTER SALES SUPPORT
21
1300 855 831
support@scheppach.com.au
MODEL: HCE2400 PRODUCT CODE: 62005 09/2018
AUS
HCE2400 Before Operation/Operation
