4 5
3. Parts description
WARNING! To reduce risk of injury, only use 20V Xfinity Plus
battery packs. Other type of battery packs may burst causing personal
injury and damage. The battery pack must be recharged only with a
20V Xfinity Plus battery charger
WARNING! Please read and understand this instruction manual
before use and keep it for your future reference. Your power tool
should only be passed on together with this instruction manual.
 LED light
 Allen Key
 Blade rotation
indicator
 Trigger switch
 Lock off button
 Motor housing
 Main handle
 Front handle
 Bevel adjustment knob
 Bevel scale
 Parallel guide locking knob
 Parallel guide
 Blade guard lever
 Lower blade guard
 Base plate
 Upper blade guard
 Dust extraction BEBQUFS
 Depth locking lever
 Depth of cut
indicator
 Spindle lock button
 Blade
 Blade guide notch
 Parallel guide slots
 Blade bolt
 Inner blade flange
 Outer blade flange
 Battery Pack (
NOTINCLUDED
SHOWNONLYFORILLUSTRATIVEAND
INSTRUCTIONALPURPOSESONLY
)
 Battery Pack release tab
 20V Charger (NOTINCLUDED
SHOWNONLYFORILLUSTRATIVEAND
INSTRUCTIONALPURPOSESONLY
)
 Spindle
Pack c
184MM LI-ION BR
ontents / par
USHLESS CIR
ts
CULAW SAW – CS20V
1. Application
First time users or inexperienced operators pay particular attention to
the operation of the 20V Li-Ion 184mm Brushless Circular Saw, including
details of starting and stopping and correct use of the 20V Li-Ion 184mm
Brushless Circular Saw on pages, as well as the maintenance
instructions on pages .
Intended use of the the 20V Li-Ion 184mm Brushless Circular Saw
(battery / charger not included)
NOTE: This product is for private domestic DIY use only.
It is not suitable for commercial or trade use.
This 20V Li-Ion 184mm Brushless Circular Saw is used for ripping and
cross cutting of wood. Use the tool only for intended applications.
2. Package Content List
1 x Circular Saw Skin
1 x Parallel Guide
1 x Allen Key (fitted)
1 x Dust Extraction AdapterGJUUFE
1 x Instruction Manual
1 x Quick Start Guide
1 x Warranty Card
• Remove all
packing materials
• Ensure all parts on the contents
list are present
• Check the appliance, and all
accessories for transportation
damages
