WORLD TECH ELITE STRIKER-X - Drone Component Diagram; Transmitter Component Diagram

4
DRONE DIAGRAM
TRANSMITTER DIAGRAM
*Speed Control Modes:
• Low Speed: Transmitter beeps once.
• Medium Speed: Transmitter beeps twice.
• High Speed: Transmitter beeps three times.
Landing Skids
HD Picture/Video Camera
720p
Landing Skids
LED Lights
BOTTOM OF DRONE
Power
Switch
Battery
Compartment
Video Record ControlAutopilot
Antenna
Easy Mode
Speed Control*
Power Indicator
Ascend/Descend
Turn Left/Right
Turn Left/Right Trim
Power Switch
Photo Control
Flip Stunt Mode
Forward/Backward Trim
Forward/Backward
Move Left/Right
Move Left/Right Trim
LCD Screen
HD Picture/Video
Camera
Rotor
Rotor Guard
