Quick Guide
System Map: Front View with LCD Panel Open
Figure 2 - Front View with LCD Panel Open
1. Built-In PC Camera (Optional)
2. LCD
3. Speakers
4. Power Button
5. Hot-Key Buttons
6. Keyboard
7. Built-In Microphone
8. TouchPad & Buttons
9. LED Indicators
2
5
1
7
8
4
6
9
3
3
Model A
Model B
Wireless Device
Operation Aboard Aircraft
The use of any portable elec-
tronic transmission devices
aboard aircraft is usually pro-
hibited. Make sure the wire-
less modules are OFF if you
are using the computer
aboard aircraft.
Use the key combinations to
toggle power to the 3.75G/
HSPA/WLAN/Bluetooth mod-
ules, and check the LED indica-
tor/visual indicator to see if the
modules are powered on or not
(see Table 1 on page 6/
Table 3 on page 7).
2
5
1
7
8
4
6
9
3
3
14.1” WXGA
15.6” HD
