20V 5’’ Chain Saw EN
13
INTENDED USE
• The mini pruning saw is intended for cutting only wood
and branches up to a diameter corresponding to the
length of the pruning saw guide bar.
• The mini pruning saw must be used at ground level or
from a suitable platform that is completely stable and
secure.
• During using, the mini pruning saw should be held in
both hands, right hand on the trigger handle and left
hand on the top handle.
• The mini pruning saw is intended for outdoor use only.
• The mini pruning saw is not intended for any other use.
• Mounting of parts on the mini pruning saw is
authorized only for original or manufacturer-approved
spare parts (chain guides or saw chains for example)
as well as for authorized chain guide / saw chain
combinations as indicated in the manual.
• The user is responsible for any accident resulting from
improper use or unauthorized modification of the mini
pruning saw
ASSEMBLY
WARNING! Do not install the battery pack
before it has been completely assembled.
Always use gloves when handling the chain.
MOUNTING THE SAW CHAIN
1. Unpack all parts carefully. Remove the Housing-
Cover by turning the Housing-Cover Knob in a
counterclockwise direction. (See Fig. A1)
2. Place the pruning saw on a solid, level surface.
3. Use only genuine Worx chains or those
recommended for Guide Bar.
4. Slide the Chain in the slot around the Guide Bar.
Ensure the Chain is in correct running direction by
comparing it to the chain icon on the Guide Bar, or
referring to the chain direction symbol found on the
saw body. (See Fig. A2)
5. Fit the Chain onto the Drive Sprocket, so that the
Fastening Bar Bolt and the Bar Locating Tab on the
Bar Pad fit into the keyway of the opening on the
Guide Bar. (See Fig. B1, B2)
6. Assure all parts are seated properly. Make sure the
drive links are fully seated in the Drive Sprocket (See
Fig. C1), avoiding a kink as shown in Fig. C2. If kink
occurs, pick up the Chain at the Guide Bar just ahead
of the kink and then pull the kink out.
NOTE: Chain should rotate freely and be free of kinks.
7. Fit the Housing-Cover and tighten the Housing-
Cover by turning the Housing-Cover Knob clockwise
until it is tight. (See Fig. D)
WARNING: The Chain is not yet tensioned.
Tensioning the Chain applies as described
under “TENSIONING CHAIN”. The chain now needs to
be inspected to make sure it is properly tensioned.
TENSIONING CHAIN (See Fig. E1, E2, E3)
NOTE: New saw chains will stretch. Check the chain
tension frequently when first used and tighten when the
Chain becomes loose around the Guide Bar.
WARNING:
• Removing the battery pack before adjusting
saw chain tension.
• Cutting edges on chain are sharp. Use protective
gloves when handling chain.
• Maintain proper chain tension always. A loose
chain will increase the risk of kickback. A loose
chain may jump out of guide bar groove. This may
injure operator and damage chain. A loose chain will
cause chain, bar, and sprocket to wear rapidly.
1. Place the pruning saw on any suitable flat surface.
2. Loosen the Housing-Cover Knob a bit to loosen the
Housing-Cover lightly.
3. Adjust the chain tension. Turn the Chain Tensioning
Screw clockwise to tighten. (See Fig. E1)
4. The correct chain tension is reached when the Chain
can be raised approx. half the drivelink depth from
the Guide Bar in the center. (See Fig. E2) This should
be done by using one hand to raise the chain against
the weight of the machine.
5. Tighten the Housing-Cover Knob to secure the
Housing-Cover. (See Fig. E3)
NOTE: The Chain is properly tensioned when it can
be lifted off of the Guide Bar and the drivelink is
within the rail of the Guide Bar.
NOTE: The chain will naturally stretch and lose
proper tension under general use. To re-tention,
repeat steps 1-5 listed above.
LUBRICATION
NOTE: Chain life and cutting capacity depend on
optimum lubrication. Therefore, the chain should
be oiled before operation.
IMPORTANT: It is important to use bar and
chain lubricant that is formulated to perform
over a wide temperature range with no dilution
required. This can be found at the location where
you purchased this saw or your local hardware
store. Do not use dirty, used or otherwise
contaminated oil. Damage may occur to the bar or
chain. Use of non-approved oil will void the
warranty.
Do not swallow. If swallowed, call a physician
immediately. Keep out of reach of children. Store
away from heat or open flame.
1. Switch off the pruning saw and remove the battery.
2. Place the pruning saw on a level surface with the
sprocket cover facing up.
3. Clean the Guide Bar and Saw Chain with a soft brush
or solvent.
4. Apply multifunctional oil in area (a) between Guide
Bar and Saw Chain. (See Fig. F)
5. Fit the battery. Switch on the pruning saw.
Multifunctional oil is evenly distributed over the Chain.
The Saw Chain is lubricated.
OPERATION
1. BEFORE USING YOUR CORDLESS TOOL
WARNING! The charger and battery pack are
specially designed to work together so do not
attempt to use any other devices. Never insert or allow
