20V 5’’ Chain Saw EN
8
COMPONENT LIST
1. CHAIN GUARD
2. HOUSINGCOVER KNOB
3. SECONDARY GRIP AREA
4. LOCKOUT BUTTON
5. ONOFF SWITCH
6. GRIP AREA
7. BATTERY PACK
8. BATTERY PACK RELEASE BUTTON
9. CHAIN TENSIONING TOOL
10. HAND GUARD
11. HOUSINGCOVER
12. CHAIN
13. GUIDE BAR
14. CHAIN TENSIONING SCREW
15. BASE PLATE
16. BAR PAD
17. DRIVE SPROCKET
18. FASTENING BAR BOLT
19. BAR LOCATING TAB
20. BAR AND CHAIN SHEATHSCABBARD
* Not all the accessories illustrated or described are
included in standard delivery.
TECHNICAL DATA
Type Designation WG324 WG324.9 (3 - designation
of machinery, representative of battery-operated
pruning saw)
WG324 WG324.9
Voltage 20 V Max.**
Bar length 5 inch (12 cm)
Chain speed 18.4 ft/s (5.6 m/s)
Chain pitch 1/4 inch (6.4 mm)
Number of chain
drive links
32
Chain gauge 0.043 inch (1.1 mm)
Adaptive chain type
1/4LP.043 32E 40MTP
WA0142
Adaptive guide bar
type
WA0151
Charging time 1 hr
Weight (chain & bar
included)
3.9 lbs (1.8 kg) 3.0 lbs (1.4 kg)
** Voltage measured without workload. Initial battery
voltage reaches maximum of 20 volts. Nominal voltage
is 18 volts.
ACCESSORIES
WG324 WG324.9
Chain (WA0142) 1 1
Guide bar (WA0151) 1 1
Lubrication oil 1 1
Bar and Chain Sheath/
Scabbard
1 1
Charger (WA3881) 1 /
Battery (WA3575) 1 /
Only use the appropriate accessories intended for this
tool. Accessory information can be found on the product
packaging, at a Worx dealer or on our website at www.
worx.com.
