Worx WG629.1 User Manual

20V Max Lithium Portable Power Cleaner EN
12
ACCESSORIES
WG629 WG629.1 WG629.2 WG629.9
Hose 20ft.(6m) 1 1 1 1
Short lance 1 1 1 1
Extension
lance
1 1 1 1
Multi-Spray
nozzle
1 1 1 1
Carry bag 1 1 1 1
Battery pack
(WA3575)
1 1 1 /
Charger
(WA3742)
1 1 1 /
Window
squeegee with
water sprayer
(WA4050)
/ 1 / /
Brush
(WA4048)
/ 1 / /
Soap bottle
(WA4036)
/ 1 / /
Bottle cap
(WA4038)
/ 1 1 /
Only use the appropriate accessories intended for
this tool. Accessory information can be found on
the product packaging, at a WORX dealer or on our
website at www.worx.com.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
ASSEMBLY & OPERATION
ACTION FIGURE
BEFORE OPERATION
Installing the battery pack See Fig. A1
Removing the battery pack See Fig. A2
Charging the battery pack
More details can be found in WA3742’s
manual
See Fig. A3
ASSEMBLY
NOTE: The power nozzle has two
working modes: short lance only
and short lance used together with
extension lance.
Working mode 1
Attaching short lance to the power
nozzle
NOTE: When attaching, align the
two projections on the lance with the
grooves of the power nozzle as shown
in Fig. B.
NOTE: In this working mode, the
highest pressure is 94psi. it is suitable
for light duty cleaning and watering.
See Fig. B
Attaching the Multi-spray nozzle
NOTE: When attaching, rotating the
nozzle left and right to make sure the
nozzle fully seated into position and
gently pulling it to make sure it is
locked into position securely.
See Fig. C
Working mode 2
Attaching extension lance to the power
nozzle
Attaching short lance to the extension
lance
NOTE: When attaching, align the
two projections on the lance with the
grooves of the power nozzle as shown
in Fig. D, E.
NOTE: In this working mode, the
highest pressure is 320psi. it is suitable
for removing strong stains.
See Fig.
D, E
Attaching the hose to the power nozzle
NOTE: After the hose is attached, check
the connection by gently pulling upon
the hose. It should not be pulled off.
See Fig.
F1, F2
Attaching your own water hose
(optional)
1. Remove the hose adapter
2. Attach the home garden hose with
suitable connectors
NOTE: Except for the hose supplied,
you can also connect the power nozzle
to your own water hose with suitable
connectors.
NOTE: Check whether the filter screen
is missing before retightening the hose
adapter. When retightening the quick
hose adapter, please tighten securely.
Otherwise, it may not draw any water
for proper operation.
See Fig.
G1, G2, G3
OPERATION
Pressure setting
Your power nozzle has two pressure
modes.
See Fig. H
