WG743E WG743E.X Cordless Lawn mower
Starting & stopping See Fig. G1, G2
Adjusting the Cutting Height See Fig. H
Grass bag filling indicator
Empty status: flap floats (a)
Fully status: flap falls down (b)
See Fig. I1
Removing/emptying grass collection
bag
WARNING! Always check the
safety flap close the discharge
outlet before using. Never lift the
safety flap when the lawn mower
is being used without fitted grass
collection bag.
See Fig. I2
Installing the mulching insert See Fig. J
Storage
WARNING Always remove the battery
and safety key when inverted storage.
See Fig. K1, K2
BATTERY STATUS (See Fig. F)
Before starting or after use, press the button beside
the power indicator light on the machine to check
the battery capacity. During operation, the battery
capacity will be indicated automatically by the
battery power indicator.
The indicator constantly senses and displays the
battery condition as follows.
For the machine with 2 battery packs with different
power, the power indicator light displays the battery
condition with the lower one of the two batteries.
Battery power
indicator status
Battery condition
Five green lights
(
) are
illuminated.
The two batteries are in a
highly charged condition.
Two, three or four
green lights are
illuminated.
The two batteries have a
remaining charge. The more
lights are illuminated, the
more battery capacity.
Only one green
light (
) is
illuminated.
At least one battery is almost
depleted and needs to be
charged.
No light is
illuminated.
At least one battery is not fully
installed or battery may be
defective.
Only one light is
flashing twice per
cycle.
At least one battery is over
discharged (please refer to
the battery charge condition),
please recharge the two
batteries at once before use
again or storage.
Only one light is
flashing three times
per cycle.
At least one battery is hot,
wait for them cool down
before start again.
Only one light is
flashing four times
per cycle.
The machine is over load.
Raise the cutting height or
push slowly.
MOWING TIPS
NOTE: ALWAYS INSPECT AREA WHERE MOWER IS
TO BE USED AND REMOVE ALL STONES, STICKS,
WIRE, METAL AND OTHER DEBRIS WHICH MIGHT
BE THROWN BY THE ROTATING BLADE.
1. Mow across the face of slopes, never up-and-
down. Exercise extreme caution when changing
direction on slopes. Do not mow excessively
steep slopes. Always maintain good footing.
2. Release bail handle to turn mower “OFF” when
crossing any graveled area (stones can be
thrown by the blade).
3. Set mower at highest cutting height when
mowing in rough ground or in tall weeds.
Removing too much grass at one time can cause
circuit breaker to trip, which stops mower.
4. If a grass bag is used during the fast growing
season, the grass may tend to clog up at the
discharge opening. Release bail handle to turn
mower “OFF” and remove the safety key. Remove
the grass bag and shake the grass down to the
back end of the bag. Also clean out any grass
or debris which may be packed around the
discharge opening. Replace the grass collection
bag.
5. If mower should start to vibrate abnormally,
release bail handle to turn mower “OFF” and
remove safety key. Check immediately for cause.
Vibration is a warning of trouble. Do not operate
mower until a service check has been made.
6. ALWAYS RELEASE BAIL HANDLE TO TURN
MOWER “OFF” AND REMOVE SAFETY KEY
WHEN LEAVING IT UNATTENDED EVEN FOR A
SHORT PERIOD OF TIME.

Worx WG743E Specifications

General

Type	-
Cutting width	400 mm
Product color	Black, Orange
Number of wheels	4 wheel(s)
Maximum lawn area	500 m²
Maximum cutting height	88 mm
Minimum cutting height	38 mm
Number of height positions	7
Cutting clearance adjustment	Yes
Power source	Battery
Battery voltage	20 V
