15
Cordless Lawn mower EN
NOISE DATA
A weighted sound pressure L
wA
= 75dB(A)
K
pA
3 dB (A)
A weighted sound power L
wA
= 89.3 dB(A)
K
wA
3 dB (A)
Wear ear protection
VIBRATION INFORMATION
Typical weighted vibration a
h
＜ 2.5 m/s²
Uncertainty K = 1.5 m/s²
WARNING: The vibration emission value during
actual use of the power tool can differ from the
declared value depending on the ways in which the
tool is used dependant on the following examples and
other variations on how the tool is used:
How the tool is used and the materials being cut or
drilled.
The tool being in good condition and well maintained.
Using the correct accessory for the tool and ensuring it
is sharp and in good condition.
The tightness of the grip on the handles and if any anti
vibration accessories are used.
And the tool is being used as intended by its design
and these instructions.
This tool may cause hand-arm vibration
syndrome if its use is not adequately managed
WARNING: To be accurate, an estimation of
exposure level in the actual conditions of use
should also take account of all parts of the operating
cycle such as the times when the tool is switched off
and when it is running idle but not actually doing the
job. This may significantly reduce the exposure level
over the total working period.
Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades.
Maintain this tool in accordance with these instructions
and keep well lubricated (where appropriate).
If the tool is to be used regularly then invest in anti
vibration accessories.
Plan your work schedule to spread any high vibration
tool use across a number of days.
OPERATION INSTRUCTION
NOTE: : To reduce the risk of injury,
user must read instruction manual
Intended Use
This product is intended for domestic lawn
mowing.
ASSEMBLY AND OPERATION
ACTION FIGURE
ASSEMBLY
Assembling the handle bar
NOTE: Choose one of the two
holes in the lower handle for
desired handle’s height.
See Fig. A1,
A2, A3, A4,
A5
Assembling grass collection bag
See Fig. B1,
B2, B3, B4
Fitting grass collection bag to
the lawn mower
NOTE: Depress the grass
collection bag slightly to ensure
that it is completely installed.
NOTE: Take the mulching insert
out of the lawn mower before
fitting the grass collection bag.
See Fig. C1,
C2, C3
Checking the battery charge
condition
NOTE:
Fig. D1 only applies for
the battery pack with battery
indicator light.
See Fig. D1
Charging the battery pack
NOTE: The batteries are shipped
uncharged. Each battery must be
fully charged before the first mow.
Always fully charge the two
batteries at same time. More
details can be found in charger’s
manual.
See Fig. D2
