MAINTENANCE
Remove the plug from the socket before carrying
out any adjustment, servicing or maintenance.
There are no user serviceable parts in your power
tool. Never use water or chemical cleaners to clean
your power tool. Wipe clean with a dry cloth. Always
store your power tool in a dry place. Keep the motor
ventilation slots clean. Keep all working controls free
of dust. Occasionally you may see sparks through the
ventilation slots. This is normal and will not damage
your power tool.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
trOuBleSHOOtInG
1. If your power tool does not start, check the plug on
the power supply first.
2. If your hammer becomes too hot in use, set the
hammer switch to the drill mode and allow your drill
to operate at maximum speed without load for 2
minutes.
3. If your hammer work efficiency is too low, please
add sufficient grease in the grease box.
4. If your hammer use in low efficiency, please check
whether the tool is blunt.
5. If a fault can not be rectified, return the tool to an
authorized dealer for repair.
!
!
!
& ' (
) * +
, - .
# $ %
!
!
!
& ' (
) * +
, - .
# $ %
!
!
!
& ' (
) * +
, - .
# $ %

Worx WX333 Specifications

General

Drilling	Yes
Chuck type	SDS Plus
Motor type	Brushed
Screwdriving	-
Product design	Pistol grip drill
Idle speed (max)	750 RPM
Chuck capacity (max)	- mm
Impact rate (high speed)	3700 bpm
Drilling diameter in wood (max)	40 mm
Drilling diameter in steel (max)	13 mm
Drilling diameter in concrete (max)	32 mm
Product color	Black, Orange, White
Cable length	2.8 m
Output power	1250 W
Power source	AC
AC input voltage	220 V
Impact energy (max)	5 J

Weight and Dimensions

Depth	180 mm
Width	490 mm
Height	350 mm
Weight	6100 g
