Worx WX390 Manual

Cordless Rotary Hammer EN
17
ACCESSORIES
WX390 WX390.1 WX390.9
Battery charger (WA3860)
1 /
Battery pack
1 2 /
Keyless chuck with adaptor
1
HSS drill bits 2 (5mm,6mm)
Screwdriver bits
4(PH2*50mm,PZ1*50mm,PZ2*50mm, Slotted*5.5mm*50mm)
SDS drill bits
2 (6mm,8mm)
We recommend that you purchase your accessories from the same store that sold you the
tool. Use good quality accessories marked with a well-known brand name. Choose the type
according to the work you intend to undertake. Refer to the accessory packaging for further
details. Store personnel can assist you and offer advice.

Worx WX390 Specifications

General

Drilling	Yes
Chuck type	SDS Plus
Motor type	Brushed motor
Product color	Black, Orange
Power source	Battery
Impact rate	5000 bpm
Rated speed (max)	900 RPM
Rated speed (min)	0 RPM
Impact energy (max)	1.2 J
Drilling diameter in steel (max)	10 mm
Drilling diameter in concrete (max)	13 mm

Weight and Dimensions

Depth	68 mm
Width	259 mm
Height	184 mm
Weight	1250 g
