Worx WX390 Manual

Cordless Rotary Hammer EN
16
1. DUST PROTECTION CAP
2. TOOL HOLDER LOCKING SLEEVE
3. FORWARD AND REVERSE ROTATION CONTROL
4. ON/OFF SWITCH
5. BATTERY PACK*
6. HAMMER DRILL /DRILL SELECTOR DIAL
7. BATTERY PACK RELEASE CLIP
8. LED LIGHT
9. SDS KEYLESS CHUCK ADAPTOR*
10. PH2 SCREWDRIVER BIT*
11. HSS METAL DRILL BIT (5MM,6MM)*
12. SDS PLUS DRILL BITS (6MM,8MM)*
* Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
WX390 WX390.1
WX390.9
Voltage 20V
No load speed 0-900/min
Impact rate 0-5000bpm
Impact energy 1.2J
Charge time 1hr
Battery capacity
2.0Ah Li-ion
Max. drilling capacity:
Steel
10mm
Wood
13mm
Concrete
13mm
Brickwork
13mm
Machine weight 1.6kg
1.2kg

Worx WX390 Specifications

General

Drilling	Yes
Chuck type	SDS Plus
Motor type	Brushed motor
Product color	Black, Orange
Power source	Battery
Impact rate	5000 bpm
Rated speed (max)	900 RPM
Rated speed (min)	0 RPM
Impact energy (max)	1.2 J
Drilling diameter in steel (max)	10 mm
Drilling diameter in concrete (max)	13 mm

Weight and Dimensions

Depth	68 mm
Width	259 mm
Height	184 mm
Weight	1250 g
