Wren Kitchens BASE UNIT 600 - Unit Preparation and Safety Guidelines; Pre-Assembly Safety & Preparation

BASE UNIT
600 - 1000 Hob
2/3 Drawer
Carcass Assembly
For Internal Use: FI.WR.INS.058_WKIN00112_BASE_600-1000_2-3Drw_Hob_Rev1.inddPage 1
BEFORE YOU START
INSTALLATION
SHOULD BE
PERFORMED BY A
COMPETENT
PERSON ONLY.
THIS PRODUCT COULD
BE DANGEROUS
IF INCORRECTLY
INSTALLED
Standard Drawer (Packed Separately)
Fitting Pack Contents
REQUIRED TOOLS
NOT to be used
with CAM DOWEL
& CAM LOCK
DRAWER
COVER
CAP
x2
DRAWER
COVER
CAP
x2
METAL BACK PANEL
x 1
DRAWER SIDE
x1 Right Hand
DRAWER SIDE
x1 Right Hand
DRAWER SIDE
x1 Left Hand
DRAWER SIDE
x1 Left Hand
DRAWER
FRONT
FIXING
x 2
DRAWER
FRONT
FIXING
x 2
Deep Drawer (Packed Separately)
Fitting Pack Contents
(Y) x2
Gallery
Head
(J) x16
Drawer Runner
16mm Screws
(J) x16
Drawer Runner
16mm Screws
(N) x1
Door Buer
(N) x1
Door Buer
(Q) x4
21mm
Screw
(Q) x4
21mm
Screw
(L) x2
15mm
Screw
METAL BACK PANEL
x 1
DRAWER
BASE
x 1
DRAWER
BASE
x 1
DRAWER RUNNER
x 1 Right Hand
DRAWER RUNNER
x 1 Right Hand
FRONTAL
(Supplied separately)
FRONTAL
(Supplied separately)
DRAWER RUNNER
x 1 Left Hand
DRAWER RUNNER
x 1 Left Hand
GALLERY
RAIL
x 2
Fixing
clip
& (Q)
