Bulletin # 058
3 Pages
June 29, 2006
Bottom view of old routing configuration: Fig. 1
Hose routed horizontally below the hydro tank
Top view of new routing configuration: Fig. 2
Hose looped up between the hydro tank and the frame (A) and
the pump fittings are re-oriented at an angle towards the bottom of
the hydro tank to eliminate the possibility of hose binding (B)
