6-3
Operation
6.2. Operation via the Text Interface
When using the Text Interface, all switching functions are performed by
invoking simple, ASCII commands. ASCII commands are also used to display
status screens and to log out of command mode. The Text Interface includes
a Help Menu, which summarizes all available IPS commands. To display the
Text Interface Help Menu (Figure 6.3), type
/H and press [Enter].
6.2.1. The Plug Status Screen - Text Interface
When you login to the IPS command mode using the Text Interface, the first
screen displayed after login is the Plug Status Screen. The Plug Status Screen
(Figure 6.2) lists the current status of the IPS’s Switched AC Outlets and
displays the firmware version and currently defined Site I.D. Message.
Normally, the Plug Status Screen will also be redisplayed each time a
command is successfully executed. Note however, that if desired, the
Automated Mode (See Section 6.4) can be enabled to suppress the display of
the Plug Status Screen after each command.
Internet Power Switch v1.41h Site ID: (undefined)
Plug | Name | Password | Status | Boot/Seq. Delay | Default |
-----+------------------+-------------+--------+-----------------+---------+
1 | (undefined) | (undefined) | ON | 0.5 Secs | ON |
2 | (undefined) | (undefined) | ON | 0.5 Secs | ON |
3 | (undefined) | (undefined) | ON | 0.5 Secs | ON |
4 | (undefined) | (undefined) | ON | 0.5 Secs | ON |
5 | (undefined) | (undefined) | ON | 0.5 Secs | ON |
6 | (undefined) | (undefined) | ON | 0.5 Secs | ON |
7 | (undefined) | (undefined) | ON | 0.5 Secs | ON |
8 | (undefined) | (undefined) | ON | 0.5 Secs | ON |
-----+------------------+-------------+--------+-----------------+---------+
“/H” for help.
IPS>
Figure 6.2: Plug Status Screen - Text Interface (IPS-800 Shown)
