1717
1717
17
1616
1616
16
CC
CC
C
ONTROLLINGONTROLLING
ONTROLLINGONTROLLING
ONTROLLING
ANAN
ANAN
AN
IR MIR M
IR MIR M
IR M
INIINI
INIINI
INI
C C
C C
C
ONTROLLERONTROLLER
ONTROLLERONTROLLER
ONTROLLER
(IR543) (IR543)
(IR543) (IR543)
(IR543)
If you already own an IR Mini Controller,
you will need to change the X10 Home
Automation code in the remote to use it.
The code for standard X10 RF Home
Automation is 999. The code to control
the IR Mini Controller is 998. To change
the code:
2.2.
2.2.
2. Press and release
the X10 button.
3.3.
3.3.
3. Enter 998 to control
an IR Mini
Controller, or 999
for standard X10
control. The LED
turns off after the
last digit entered.
Note: In most cases, you will not need to
use the IR Mini Controller to receive
commands from the X10 Platinum Remote
– the Transceiver Module does this for
you and has the added advantage of
working through walls. You can if you
wish control the IR Mini Controller and
the Transceiver Module at the same time.
To do this stores code 999 under the
X10 key and store 998 under any other
key (except TV). See page 20 for more
info on using an IR543.
1.1.
1.1.
1. Press and hold
SETUP until the LED
indicator lights
steadily. Release
the SETUP button.
CC
CC
C
HANGINGHANGING
HANGINGHANGING
HANGING
THETHE
THETHE
THE
X10 H X10 H
X10 H X10 H
X10 H
OUSEOUSE
OUSEOUSE
OUSE
CC
CC
C
ODEODE
ODEODE
ODE
::
::
:
The X10 Platinum Remote defaults to
House Code A, and in most cases you
will not need to change this unless you
are experiencing interference from a
neighboring X10 system.
1.1.
1.1.
1. Press and release
the X10 button.
2.2.
2.2.
2. Press and hold
SETUP until the LED
indicator lights
steadily. Release
Setup button.
3.3.
3.3.
3. Use the number
buttons to enter the
number equivalent
to the chosen
House Code
(1=A, 2=B ..16=P).
4.4.
4.4.
4. Press the ENTER
button to confirm
the House Code.
The LED turns off.
Note: The House Code you choose must
match the House Code on the
Transceiver and Modules you are using it
with.
