IO Ports
Functions
B
Battery, use Lipo battery (3S~6S, 11.1V~28V) supply power for SuperX
system
X
Expansion
G
Attitude Gain
S
Safe Mode
M
Flight Mode
R
RUDD / Yaw
T
Throttle
E
ELEV / Pitch
A
AILE / Roll
IO Mode output ports
IO Ports
Functions
M1
ESC
M2
ESC
M3
ESC
M4
ESC
M5
ESC
M6
ESC
M7
ESC / Gimbal Pitch servo
M8
ESC / Gimbal Roll servo
GB
Gimbal power supply input: can use separate UBEC to power up Gimbal
through M7 and M8.
Notice: When SuperX configured as 7 or 8 rotors, M7 and M8 is ESC output; when SuperX
configured as 2 to 6 rotors, M7 and M8 is Gimbal servo output.
