Xaircraft SuperX User Manual

6
©2013 XAircraft All Rights Reserved.
SuperX Flight Mode
Flight Mode
IO
Functions
Explanation
Manual Mode
M
No Auto Horizontal ability.
Not recommended
for beginners.
Attitude Mode
(ATT Mode)
Auto horizontal after sticks released.
Height hold.
GPS Attitude Mode
(GPS ATT Mode)
GPS signal is good:
Auto horizontal after
sticks released and
enter GPS position
hold.
Height hold.
When M input
unconnected,
SuperX is in GPS
ATT Mode by
default.
 GPS Module
unconnected or
GPS signal lost;
 Weak interference
of magnetic
ATT Mode
Safe Mode
S
Autopilot Mode in accident, Return to Home
(tail in) and auto landing by default.
LED Indication
XAircraft LED design principle: on ground, Red lamp flashing means not allow to fly; Red lamp
flashing in the air, user should land it urgently then check.
LED
Shows Status
Flight Status
Fast Green flashing
Flight Mode: Manual Mode
Slow Green flashing
Flight Mode: ATT Mode
Slow Green-Green flashing
Flight Mode: GPS ATT Mode
Slow Green-Red flashing
Flight Mode: GPS ATT Mode（No GPS signal or signal is weak）
Slow Red-Red flashing
Flight Mode: Safe Mode
Calibration and Firmware upgrade
Fast Green-Red flashing
When LED starts alternating green and red flashing, indicates one of
the following:
1） Flight Controller system entered Calibration Mode.
2） SuperX is upgrading firmware.
Error status
