26 Freedom SW 3000 Installation Guide
Installing the Inverter/Charger
6. Tighten the terminal screws. Leave some slack wire inside the wiring
box.
7. Connect the ground wires to a free position on the ground bus, Figure
4 on page 24. If solid ground wire is being used, the wire can be
connected directly under the screw heads. If stranded ground wire is
being used, ring terminals must also be used.
8. Secure the strain-relief clamp on the AC output cable jacket.
9. Attach the wiring compartment cover panel and tighten the four
screws.
10. Connect the outgoing AC wires to an AC load panel equipped with
circuit breakers.
Terminals Line for Dual Output
Lines for Single
Output
N Neutral 2 Unused
L2 Line 2 Unused
N Neutral 1 Neutral
L1 Line 1 Line
