38 Freedom SW 3000 Installation Guide
Installing the Inverter/Charger
Step 8: Testing Your Installation
There are several tests to be performed for testing your installation. These
tests will verify that:
the Freedom SW 3000 works in invert mode,
the Freedom SW 3000 works in charge mode, and
the Freedom SW 3000 works in AC bypass mode.
If the test fails at any point, go to “Step 7: Performing Checks Prior to
Initial Start-Up” on page 37 and go through the checklist again to check the
installation. Then perform the test again. If the test fails again, see the
troubleshooting section in the Freedom SW 3000 Sine Wave Inverter/
Charger Owner’s Guide.
Testing in Invert Mode
To test the Freedom SW 3000 in invert mode, using a 100 watt light
bulb as the test load:
1. Close the DC disconnect switch or the DC circuit breaker to supply
DC power to the Freedom SW 3000.
Wait for all the lights on the front panel to flash on and off, indicating
that the unit has successfully initialized (10 to 30 seconds).
If the light does not come on, make sure the voltage at the DC
terminals on the Freedom SW 3000 is correct, as described in “Step 7:
Performing Checks Prior to Initial Start-Up” on page 37.
ELECTRICAL SHOCK HAZARD
The Inverter Enable button on the Freedom SW 3000 and the optional
accessories do not disconnect DC or AC input power to the Freedom SW
3000.
Failure to follow these instructions can result in death or serious
injury.
Figure 13
Freedom SW 3000 Front Panel
FREEDOM SW 3000
Inverter
Reset Enable
Inverter AC/
On Charge Fault
Xanbus Interface
