Xantrex SW Series User Manual

INDEX
Page
142
 2001 Xantrex Technology, Inc.
5916 - 195th Street N. E.
Arlington, WA 98223
Telephone: 360/435-8826
Fax: 360/435-2229
www.traceengineering.com
SW Series Inverter/Charger
Part No. 2031-5
Rev. C: February 2001
User Settings .............................................................. 123
Setup Menu – 12 VDC ............................................ 124
Setup Menu – 24 VDC ............................................ 125
Setup Menu – 48 VDC ............................................ 126
User Menu ..............................................................123

Xantrex SW Series Specifications

General

Input Voltage	12V, 24V, or 48V DC
Output Voltage	120V AC
Waveform	Pure Sine Wave
Output Frequency	60 Hz
Operating Temperature	-20°C to +50°C
Battery Charger	Yes
Protections	Overload, Over-temperature, Short Circuit
