Xantrex SW Series User Manual

MENU SYSTEM
Page
54
 2001 Xantrex Technology, Inc.
5916 - 195th Street N. E.
Arlington, WA 98223
Telephone: 360/435-8826
Fax: 360/435-2229
www.traceengineering.com
SW Series Inverter/Charger
Part No. 2031-5
Rev. C: February 2001
BATTERY SELLING (17) MENU HEADING
Note: See the battery section of this manual for recommended settings for different battery types.
Set Battery Sell
volts DC 13.4
Set Battery Sell
volts DC 26.8
Set Battery Sell
volts DC 53.6
12 VDC models
Range: 5.0 to 16.0
24 VDC models
Range: 10.0 to 32.0
48 VDC models
Range: 20.0 to 64.0
Sets the level to which the batteries will be discharged when power is being sold from the batteries to the
grid. This is only used if the SELL mode is enabled and the GRID USAGE TIMER (18) is programmed.
This setting will not be adjusted for the battery temperature if the temperature sensor is installed.
Set Max Sell
amps AC 30
Set Max Sell
amps AC 15.0
Set Max Sell
amps AC 35
Set Max Sell
amps AC 16.5
Standard models
Range: 01 to 35
“E” models
Range: 01 to 18
“J & K” models
Range: 01 to 40
“W” models
Range: 01 to 18
Sets the maximum AC amps allowed to be delivered to the utility grid from a solar array and/or the
batteries during utility interactive operation. This is only used if the SELL mode is enabled. If batteries are
being “sold” into the utility grid, this setting together with the SET BATTERY SELL VOLTS DC setting
determines the depth of discharge the batteries will experience. Note: The default setting will vary
between models with different continuous output power ratings.
INFORMATION DISPLAY
The following information is displayed as additional Menu Items.
See menu 9 to enable SELL mode. Make sure LBX is above LBCO volts.
GRID USAGE TIMER (18) MENU HEADING
The Grid Usage Timer selects when power may be drawn from the utility grid for battery charging. It is
used only when either the FLT or SELL modes are selected in the SET GRID USAGE menu item under
the INVERTER SETUP (9) menu heading. Utility Power must be connected to the AC1 for this timer to be
operational.
Start Charge
time 21:00
End Charge
time 21:00
All Models
Range: 00:00 to 23:50
All Models
Range: 00:00 to 23:50
FLT mode: After the START CHARGE TIME, the inverter turns on the battery charger, connects the
utility grid and powers the AC loads from the utility grid and charges the battery to the FLOAT VOLTS DC
setting. At the END CHARGE TIME, the inverter disconnects from the utility grid and powers the loads
from the battery.
SELL mode:
• With the GRID USAGE TIMER enabled (the START CHARGE TIME is different from the END
CHARGE TIME), the inverter will charge the battery to the FLOAT VOLTS DC setting at the START
CHARGE TIME. After the END CHARGE TIME, the inverter turns off the battery charger and begins
to “sell” power into the utility grid from the battery (or any other DC sources available and connected to
the batteries) to the SELL VOLTS DC setting. The current will be limited to a maximum level
controlled by the MAX SELL AMPS AC menu item setting under the BATTERY SELLING (17) menu
heading.
• With the GRID USAGE TIMER disabled (the START CHARGE TIME beginning time is equal to the
END CHARGE TIME), the inverter will use the utility grid (or any other DC sources available and
connected to the batteries) to maintain the batteries to the FLOAT VOLTS DC setting.
In the SELL mode, battery voltage will be held near the SET BULK VOLTS DC setting for the adjustable
ABSORPTION TIME period setting after an AC failure or upon encountering a BULK CHARGE TRIGGER
TIMER event.

Xantrex SW Series Specifications

General

Input Voltage	12V, 24V, or 48V DC
Output Voltage	120V AC
Waveform	Pure Sine Wave
Output Frequency	60 Hz
Operating Temperature	-20°C to +50°C
Battery Charger	Yes
Protections	Overload, Over-temperature, Short Circuit
