©2000 Xantrex Technology Inc.
Figure 12
Configuration Jumpers Location
EQ/LVR JUMPER
CHARGE/LOAD
CONTROL JUMPER
RESET SWITCH
SYSTEM VOLTAGE
JUMPER
24
3.0 INSTALLATION
NICAD SETTING
SELECTION RESISTOR
