Xantrex XPower 1500 User Manual

975-0558-01-01 19
Specifications
NOTE: Specifications are subject to change without prior notice.
Electrical Specifications
Output power at 77 º F (25 ºC) ambient
temperature and 12 VDC input:
Maximum continuous output power
Maximum surge power
1500 W
3000 W
Operating temperature range 0–40 °C (32–104 °F)
Output voltage 115 Vac RMS ± 5%
Output waveform Modified sine wave
Output frequency 60 Hz ± 1 Hz
Input voltage 10.5–15.5 Vdc
Low battery alarm 11.0 V
Low battery cutout 10.5 V
Optimum efficiency 90%
No load current draw <0.3 A
Regulatory Approvals
Safety UL 458
Physical Specifications
Base Unit Dimensions and Weight:
L × W × H 382×151×75 mm (15×5.9×3 in.)
Net Weight 2.7 kg (5.95 lbs)
