5 Status Display: Shows Voltage, Current or AC Power.
VOLTAGE: Indicates battery voltage at the input terminal of the
inverter in volts (V).
CURRENT: Indicates current drawn from the battery by the inverter
in amps (A).
AC POWER: Indicates the output power being drawn from the
inverter in utilized kilowatts (kW).
6 Display Function Button Press this to display battery voltage,
battery current and AC output power.
7 Remote On/Off Switch Connector Port: For connecting the
Remote On/Off Switch. The remote switch and a 10-foot
communications cable is included with the inverter.
8 Two duplex GFCIs: Each GFCI has two three-prong AC outlets and
is connected in series with a 20 A circuit protector.
9 Two 20 A circuit protectors
10 Mounting Flanges (front and rear) allow you to mount the inverter
permanently.
11 Ventilation Openings must not be obstructed for the proper
operation of the inverter.
12 AC Knockout with strain-relief clamp: For hardwiring the inverter
and securing the cables.
