Copyright | C2EU Software Service Manual, Version 1.0.0
3. Driver software update
When it’s needed to upgrade the driver software in C2EU, please follow the steps below:
1) Receive the new version of driver software -update.zip and command- from XCharge.
2) Then open the ADB tool like shown in 1. Part. After adb remount execute command " adb
push C:\Users\admin\Desktop\command /cache/recovery/command".
3) Execute command " adb
push C:\Users\admin\Desktop\update.zip /cache/recovery/update.zip".
4) Execute command
“
adb shell”.
5) Execute “reboot recovery” and then C2EU will restart automatically to finish the update.
Note:
C:\Users\admin\Desktop\........ is the local address of file in your computer that you received
from XCharge, /cache/recovery/…… is the target address in C2EU for corresponding file, please
do not change its name for such updates. Here is just an example, be careful of the space in
command.
4. Connection with OCPP backend
4.1 Communication Protocol Settings
1) Connecting a wired mouse to the charging station.
2) Clicking with the left mouse button on the logo area in the upper part of the
screen to get to the configuration page.
3) Select "Protocol setting", select the desired protocol, e.g. OCPP, and fill out the
required information about URL, model and vendor. Click "save and reboot" to
save changes.
4.2 APN Settings
1) Turn on the C2EU to check the icon at the top of the screen. If this icon appears, it
means that there is no internet connection.
2) In the state of no internet connection, press the button at the bottom of the screen for 5
seconds, then a window will pop up. In the third line, the status of the current communication
module is shown. A sim status value of "absent" indicates that the SIM card is not detected.
