Xerox 8264E - Page 17

Xerox 8264E User Maintenance and Cleaning Guide 15
No. Name
No. Name
1 Flushing-boxes (two)
2 Flushing-box sponges
Note:
Replace the sponge on the left hand side of the printer as needed. If the left side
flushing-box is not used often and the sponge appears clean, it does not need to be
changed.
CAUTION:
 Do not drop waste fluid when replacing the flushing-box sponges. If waste fluid
comes into contact with the grid roller, the surface of the grid roller will be
damaged and the media feed function may be affected.
4. Install a new flushing-box sponge into each flushing-box.
5. Close the front cover to complete the procedure.
