Xerox AltaLink C8030 Customer Expectation & Installation Guide

I N S T A L L A T I O N A L T A L I N K
®
C 8 0 0 0 S E R I E S
Customer Expectation and Installation Guide 24
Installation Planning
Main Components
Xerox
®
C8000 is delivered with Print Engine, Scanner and Embedded Network Controller
Module Dimensions
Space Requirements / Service Space Envelope
The dimensions shown below provide the overall service space required, including the space to the nearest obstruction. The dimensions reflect both typical and
hallway installations and are absolute minimums.
Product Space Requirements
Configuration
Width
Depth
Height
Installation Space
Base Configuration
43.5 in / 1,107mm
27.5 in / 699mm
45.2 in / 1,149mm
61.2” x 81.4”
1554 mm x 2067mm
Base Configuration + Integrated Finisher (Up to 35ppm only)
44.4 in / 1,129mm
27.5 in / 699mm
45.2 in / 1,149mm
61.2” x 81.4”
1554 mm x 2067mm
Base Configuration + Office Finisher LX
(Booklet Maker)
65.6 in / 1,666mm
27.9 in / 709mm
45.2 in / 1,149mm
78.2” x 81.4”
1986 mm x 2067 mm
Base Configuration + Business Ready Finisher
69.9 in / 1,776mm
27.5 in / 699mm
45.2 in / 1,149mm
90.2” x 81.4”
2220 mm x 2067 mm
Base Configuration + Business Ready Booklet finisher
72.3 in / 1,837mm
27.5 in / 699mm
45.2 in / 1,149mm
92.6” x 81.4”
2352 mm x 2067 mm
Base Configuration + Business Ready Booklet finisher + C/Z
folder
81.5 in / 2070.2mm
27.5 in / 699mm
45.2 in / 1,149mm
101.8” x 81.4”
2586 mm x 2067 mm
Base Configuration + Business Ready Booklet finisher + C/Z
folder +High Capacity Feeder
81.5 in / 2070.2mm
27.5 in / 699mm
45.2 in / 1,149mm
101.8” x 81.4”
2586 mm x 2067 mm
7. Device Direct (DD) Communications:
Each device will need to be communicating to Xerox through the internet via the Xerox Device Direct method for Remote Diagnostics
support. Follow the steps below (customer) to find how to setup Device Direct, if required.
Setting up Device Direct:
A) Go to the “Support and Drivers” link on Xerox.com.
 Search for your product, then click on the Support link for that product.
 In the search field, enter "Enroll Xerox Remote Services" and follow the instructions provided.
B) If the search does not return any instructions:
 Click on the Documentation link for your product.
 Open the System Administrators Guide and refer to the section of the guide which provides information Xerox Remote Services
Setup and follow the steps provided.
X
X
X
Dimensions and Weights
Configuration
Width
Depth
Height
Weight
Base Configuration
25.2 in. / 640mm
27.5 in / 699mm
45.2 in / 1,149 mm
321 lbs / 151.9 kg
With Integrated Office Finisher (30/35ppm only)
27.8 in / 705mm
27.5 in / 699mm
45.2 in / 1,149 mm
348 lbs. / 158 kg
With Office Finisher LX (Booklet Maker)
48.8 in / 1242mm
27.9 in / 709mm
45.2 in / 1,149mm
390 lbs. / 177.2 kg
With Business Ready Finisher
51.3 in / 1302mm
27.5 in / 699mm
45.2 in / 1,149 mm
430.4 lbs. / 195.3 kg
With Business Ready Booklet Maker Finisher
56.4 in. / 1,431.4mm
27.5 in / 699mm
45.2 in / 1,149 mm
467.1 lbs. / 212.3 kg
Base configuration + Business Ready Booklet finisher + C/Z folder
65.5 in. / 1664.2mm
27.5 in / 699mm
45.2 in. / 1,149.2 mm
581.7 lbs. / 264.4 kg
Base configuration + Business Ready Booklet finisher + C/Z folder
+ High Capacity Feeder
77.9 in. / 1978.2mm
27.5 in / 699mm
45.2 in. / 1,149.2mm
645.5 lbs. / 293.4 kg
