Page 21 of 28 701P42081
S
S
c
c
a
a
n
n
t
t
o
o
F
F
T
T
P
P
/
/
S
S
M
M
B
B
S
S
e
e
t
t
u
u
p
p
Files can be scanned on the M123/M128 device and routed on to a server or a client using FTP or SMB protocol. Directory structures (repositories)
need to be created on the server to hold the scanned documents. It is assumed that an FTP server/client or an SMB server/client exists and is
configured on the network.
Prerequisite
Complete the Network Installation. Refer to Æ General Network Setup
Complete DNS/WINS set up if Host names are provided for the mail servers, rather than IP addresses. Refer to
Æ
Advanced Network Setup
Scan to FTP/SMB Setup
Field Name Description Location Scan
To
FTP
Scan To
SMB
Value
Enable
“TCP/IP” Port”
Port by which TCP/IP client
communicates with the
TCP/IP server
WUI:
Properties Æ Port Settings
LUI:
System Settings Æ System Settings Æ
Network Settings Æ Port Settings
R R
Enable “FTP
Client” Port
Port by which FTP client
communicates to the FTP
server
WUI:
Properties Æ Port Settings
LUI:
System Settings Æ System Settings Æ
Network Settings Æ Port Settings
R NR
Enable “SMB
Port”
Port by which SMB client
communicates to the SMB
server
WUI:
Properties Æ Port Settings
LUI:
NR R
