General Network Setup
Field Name Description Location Value
Settings Æ Protocols Settings
Subnet Mask The Subnet mask address of the
device. The Subnet Mask identifies
which part of the IP Address contains
the Subnet Address and which part
contains the host (or device) address.
WUI :
Properties Æ Protocol Settings Æ TCP/IP
LUI :
System Settings Æ System Settings Æ Network
Settings Æ Protocols Settings
_____._____._____._____
Ex: 255.255.255.0
Gateway
Address
The Gateway Address is the IP
Address of the gateway, or router, that
the machine will use to access devices
on other subnets.
WUI :
Properties Æ Protocol Settings Æ TCP/IP
LUI :
System Settings Æ System Settings Æ Network
Settings Æ Protocols Settings
_____._____._____._____
Ex: 192.168.1.1
A
A
d
d
v
v
a
a
n
n
c
c
e
e
d
d
N
N
e
e
t
t
w
w
o
o
r
r
k
k
S
S
e
e
t
t
u
u
p
p
DNS and WINS information has to be populated if a server name has been specified. DNS and WINS are protocols that allow the device to use
names rather then IP addresses when specifying the hosts of services that the device uses (ex: LDAP Host, Kerberos Host, SMTP/ pop3 Host, etc).
Prerequisite
Complete the Network Installation. Refer to Æ General Network Setup
Advanced Network Setup
Field Name Description Location Value
DNS Server
Address (up to 3
DNS server
addresses can be
specified)
Dynamic Name Service. Specifying
hosts by IP address is error prone and
difficult. DNS allows names to be
assigned to IP addresses. A DNS
server allows a client (like
WUI :
Properties Æ Protocol Settings Æ TCP/IP
_____._____._____._____
Ex: 192.168.1.2
If DHCP box is check via
Web UI, then DNS address
