Page 5 of 28 701P42081
Purpose
This document is intended to help the support centers and analysts in enabling Networking and Scanning features for use on a M123/M128 device.
This document is not a substitute for the system administrator’s guide or the user guide, rather it is intended to be used as a quick reference or
checklist when enabling the scanning features.
G
G
e
e
n
n
e
e
r
r
a
a
l
l
N
N
e
e
t
t
w
w
o
o
r
r
k
k
S
S
e
e
t
t
u
u
p
p
These are the minimal settings required to enable the device on the network.
General Network Setup
Field Name Description Location Value
Host Name The device’s SMB Host Name. WUI :
Properties Æ Protocol Settings Æ TCP/IP
Ex: XRXxxxxxxxxxxxxxx
Enable “TCP/IP”
Port
Port by which TCP/IP client
communicates with the TCP/IP server
WUI :
Properties Æ Port Settings
LUI :
System Settings Æ System Settings Æ Network
Settings Æ Port Settings
Get IP Address
The Method used to get an IP address.
Examples are;
•
DHCP or
• Manual,
• Etc.
WUI :
Properties Æ Protocol Settings Æ TCP/IP
LUI :
System Settings Æ System Settings Æ Network
Settings Æ Protocols Settings
Default is DHCP Auto.
Note: If set for anything
other than Manual, skip
IP Address, Subnet
Mask and Gateway
fields.
IP Address
This is Sheeta’s TCP/IP Address.
The IP Address is a unique address
that identifies a device in a network.
WUI :
Properties Æ Protocol Settings Æ TCP/IP
LUI :
S
