7.9 Cleaning the Printer 191
Feed Rolls Inside the Printer
1. If paper is loaded in the bypass tray,
remove the paper and close the bypass
tray cover.
Important
• When closing the bypass tray cover, be careful not to
get your fingers caught between (the left and right
edge of) the cover and the printer.
2. Pull the front cover release levers ("A") on
both sides of the printer towards you and
open the front cover.
3. Identify the location of the feed rolls.
4. While rotating the feed rolls, wipe the
rubber part with a soft, firmly wrung cloth
moistened with water.
5. Open the front cover.
To Next Page
